Gen 2 Relay Mod to upgrade the capacity of the Gen 2 Raptor, 100A max, and comes with 4-30A, 1-10A and fuse with 6-35A mini relays. Unit is weatherproof with sealed wire opening and is intended to be underhood mounted. Unit comes with #8 Power wire with 100A main fuse, ground wire and trigger wires to be tied to the existing factory AUX switch wires under the hood. The unit also comes with a Trigger Wire to use your factory hi-beam switch or technoligy pack to turn on all off-road lights. ( For Off-Road Use Only*) This system utilizes the number 6 AUX switch to allow the Hi-beam trigger to work. (Contact Keith for option with Gen 3 vehicles)
Gen 2 Relay Panel with 5 Ckts, 5 High Beam Diodes / Controlled by #6 Switch
The stock unit has diode in all four locations, If you do not want the unit to turn on a rear light with the Hi-Beam switch simply remove the diode like a fuse is pulled. (Controls Aux items on switches 1-4)
